PRODUCTS


Abletech develops, produces,
and supplies the sensors for vehicle and industrial safety.

RUSS1000DB

Producing firm and clear rear camera
is protecting the worker.


  • 상품간략정보 및 구매기능


    Installation possible vehicle 트럭,버스,특장차,승합,승용차
    Connection wire 무선
    Certification KC
    Used voltage 12V / 24V 겸용
    Pixel 200만화소
    Viewing angle 155도
    Waterproof I

    Product Overview

    Abletech wireless rear blind spot detector is easily installed and operated in small to large vehicles. With stable performance and reliable quality, it is designed to have structure that ensures convenient installation.


    The sensor can use channels from 2 to 4. Depending on the vehicle, attached sensor or embedded sensor can be installed. Both features superior detection performance with complete waterproof structure.


    It senses minimum distance of 30cm and maximum distance of 2.5m, displaying the location detected in the left and right sensors using 4 divided areas.The detector alarms the driver with 7 segment of LED light in the unit of 10cm using display, and 4 types of beeping sound.


    This miniature size control box uses wireless communication, therefore does not require electric wiring. It offers convenient installation and maintenance while warning the driver and displaying the distances.


    Within the wireless communication distance (L.O.S. standard),the power source used can be used with FREE VOLTAGE in the voltage range of 7 ~ 40V.It also boasts a long life of more than 10 years.


    Abletech, who have acquired the patented technology, supplies the product after producing in Korea.

    Product Specifications

    ITEM RUSS1000DB
    Supply Support +24VDC+/-10%(12.24V FREE
    Supply current 3A Max
    Print 50W Max.
    Operating temperature -30 ˚~+60 ˚
    Scanning Frequency NTSC : [ H ] 15.734 KHz x [ V ] 59.94 Hz
    PAL : [ H ] 15.625 KHz x [ V ] 50 Hz
    dB 80dB
    Wireless distance 50m (Unobstructed Open Space)

    Download

    Classification File Last modified date
    Product Specification 0000-00-00
    Manual 0000-00-00
    CAD 0000-00-00
    Test report 0000-00-00
    Product certificate 0000-00-00
