Abletech develops, produces,
and supplies the sensors for vehicle and industrial safety.

RUSS1000E

Producing firm and clear rear camera
is protecting the worker.


  • 상품간략정보 및 구매기능


    Installation possible vehicle 트럭,버스,특장차,승합,승용차
    Connection wire 무선
    Certification KC
    Used voltage 12V / 24V 겸용
    Pixel 200만화소
    Viewing angle 155도
    Waterproof I

    Product Overview

    The wireless rear-end detector provides clear picture quality for driver's vision, monitoring and operation, and provides a stable rear view with rugged durability even in harsh outdoor work environments.


    To become one of the technology leaders in the field of wireless rear-end detectors, AbleTech has developed the following features.


    The RUSS1000E Rear Detector has a brilliant color feel compared to competitors' products, and the enclosure is made of zinc and is resistant to corrosion. Therefore, it can be used for a long time without being influenced by external environment.


    Wireless communication range for L.O.S between sensor, wireless transmitter, and control box is more than 50m. In vehicles, it is possible to wirelessly communicate with the wireless receiver of the driver's seat that is more than 20 meters away.


    It senses minimum distance of 30cm and maximum distance of 2m, indicating the alarming status to the driver with various alarm sound depending on the distance.

    Product Specifications

    ITEM RUSS1000E
    Working Voltage 12V,24V(+7V~ +40V)
    Power consumption 1W MAX(max.150mA)
    Operating temperature -30˚~+70˚
    Sensing distance 30cm ~ 3M(basic) ~ maximum 5M(OPTION)
    Channel used Basic 2CH, (option3~6cH)
    Alarm display Basic 2~4LAMP RED LAMP Indicator

    Download

    Classification File Last modified date
    Product Specification 0000-00-00
    Manual 0000-00-00
    CAD 0000-00-00
    Test report 0000-00-00
    Product certificate 0000-00-00
