ENGLISHProduct Overview
AbleTech rear camera provides clear picture quality for the driver to ensure visibility and complete monitoring of the surrounding when driving a vehicle. The strong durability guarantees a stable rear image even in roughoutside work environments.
To become one of technology leaders in wireless rear camera industry, Abletech developed a product with following feature.
The RCS3000D Rear Camera boasts brighter colorscompared to other competing products, and it is resistant to corrosion becauseit is made of zinc. Therefore, it can be used for a long time without being influenced by external environment.
Product Specifications
| ITEM | RCS3000D |
|---|---|
| Image orientation | Reverse image |
| image sensor | 1/3", 320K pixel |
| Signal method | NTSC,(h)656 x (V)492 |
| Minimum preparation amount | 0.1lux |
| Power | 12V |
| Current consumption | 60mA |
| Operating temperature | -30˚C ~ 80˚C |
| White balance | Automatic |
| Mirror function | Automatic mirror system |
| Waterproof grade | IP 67 |
| Video output | IV P-P (750hm) |
| Lens angle | 170 (standard) |
| Resolution | 420 TV line |
| Signal-to-noise ratio | 48dB min |
| Size | 29.7mm(W) ~ 24.5mm(H) x 25.5mm(D) |
Download
| Classification | File | Last modified date |
|---|---|---|
| Product Specification | 0000-00-00 | |
| Manual | 0000-00-00 | |
| CAD | 0000-00-00 | |
| Test report | 0000-00-00 | |
| Product certificate | 0000-00-00 |
