KOREA제품개요
AbleTech rear cameraprovides clear picture quality for the driver to ensure visibility and complete monitoring of the surrounding when driving a vehicle. The strong durability guarantees a stable rear image even in roughoutside work environments.
To become one of technology leaders in wireless rear camera industry, Abletech developed a product with following feature.
The RCS4000 Rear Camera boasts brighter colorscompared to other competing products, and it is resistant to corrosion becauseit is made of zinc. Therefore, it can be used for a long time without being influenced by external environment.
When installed in the camper trailer in white color, it is also nice to look at.
· Screen resolution: produce bright screen with high resolution of 52,000 pixels
· Viewing angle: features excellent viewing angle of 155 degrees.
· Enclosure material: boasts long life of more than 10 years because it is made of zinc material which offers strong resistance to corrosion.
· orean Product: Abletech, who have acquired the patented technology, supplies the product after producing in Korea.
제품사양
| ITEM | RCS 4000 |
|---|---|
| Image Sensor | 1/3” SONY & SHARP SUPER CCD, [ High Sensitivity ] 52K Pixels ( Opt. 41k/27k ) |
| Effective Pixel | [ H ] 510 x [ V ] 492 [ NTSC ] / [ H ] 500 x [ V ] 582 [ PAL ] |
| Scanning System | 2:1 Interlacing / 525 Lines [ NTSC ], 625 Lines [ PAL ] |
| Sync. System | Internal Sync |
| Scanning Frequency | NTSC : [ H ] 15.734 KHz x [ V ] 59.94 Hz PAL : [ H ] 15.625 KHz x [ V ] 50 Hz |
| Horizontal Resolution | More Than 380 TV Lines |
| Video Output | VBS 1.0 Vp-p ± 10% / 75Ω |
| S/N Ratio | 50 dB Min [ ACC off, Y signal ] |
| Min. Illumination | 0.1 Lux at F 2.0 AGC ON |
| Lens | f-2.9mm, View 155˚ [ Dia. ] ( Opt. 120˚ ) |
| Gain Control | Autormalic Gain Control |
| Gamma | 0.45 |
| Shutter Speed | Electronic Auto Iris 1/50 ~ 1/100,000 : PAL/1/60 ~ 1/100,000 : NTSC |
| Input Voltage | DC 9V - 30V [ DC 12V, 150mA MAX ] |
| Ambient Temperature | - 20˚C ~ 70˚C, 85% RH |
| Mirror | ON / OFF |
| BLC | YES |
| IR LED | 850nm IR LEDs 5EA / CDS Sensor 1EA |
| Night View Distance | Outdoor 15m ~ |
| MIC | 44dB( Opt. ) |
| Housing Color | Black, Silver |
| Connector | S-Pin Din, 5.5mm Dc Jack, RCA(m) |
| Weight | Approx, 474g |
| IP Resistance | Certified IP 67 Level |
| Approval | CE, FCC, e-mark |
